PLASTIC BUTTERFLY VALVES





Full plastic butterfly valves in Polypropylene, PVC, U-PVC, C-PVC and PVDF. These work well in a variety of applications especially with low concentrate acid environments ranging up to 120 Degree Celsius. Seals used internal are EPDM, or VITON for a full overaul protection. Our butterfly valves are  available in DIN or ANSI. These are commonly used by very demanding industries such as Chlorine, Bromine, Sulphuric Acid, Hydrochloric Acid (HCL), Pharmaceutical, Chlorinated Paraffin Wax, acid chemical and food industry.



These valves are available from DN50 up to DN200 depending on the material of plastic all of which the pressure rating is PN10.





TYPES OF BUTTERFLY VALVES:



Hand Lever Wafer Type

Hand Wheel Wafer type

Hand Lever Wafer flanged Type

Hand Wheel Wafer flanged type



Pneumatic Actuated

Electric Actuated

CONNECTION TYPE



Available with drillings in Class 150, 300, BS4504, PN10/16 or SANS 1000/3. Special drilling on request. All our valves are fully tested to ensure the highest of quality standard and supplied with material and test certifcation.
